- 烫辊的外层用抗腐蚀材料制作。36只外部连续的铠装电阻加热器组成加热系统，可按照要求的温度予以加热，其温度由电子调控器控制，我们的专用热电偶能够反映烫辊表面温度， 表面温度均匀，促使毛皮烫毛达到深度和光亮要求。
The traditional product – GI-70-H Ironing Machine of Tianjin Giantey Machinery Co., Ltd. has been well developed and improved in functions and quality after several years’ effort in practice. Now it is well accepted among the clients from home and abroad, it is the most important equipment and the first selection for all the customers in their processing facilities for the production of the lambskin (and other small skins such as rabbit, mink, fox, etc).
Our hydraulic ironing machine is warmly welcome in the tanneries and well done with the help from our friends such as the devotional Turkish, the earnest German, the romantic French, the traditional Spanish, and the industrious Chinese, it is specialized in the following characteristics:
High production speed and efficiency through the operation electrical and hydraulic system.
The operator could adjust the working speed freely by changing the running speed of the felt apron, and he could also adjust the pressure acting on skin from the ironing cylinder and then change the contacting surface between them easily.
The ironing cylinder is well protected by four-layer of chrome-plated material, it is never to be corrupted when it touches with chemicals. 36 pcs of heating element tubes compose the heating system, evenly and smoothly located inside the ironing cylinder. The temperature is well controlled by the temperature adjustor with the communication between the adjuster and the thermocouple. All these measures make the guaranty of working, the surface of the ironing cylinder is evenly heated, and the temperature is well controlled. The result of the ironing is perfect, and finally, the double-face lambskins are well done in production and the quality becomes the best.
The machine is equipped with a control panel box, security protection system, and powerful suction motor fan.
We suggest: you should use the ideal ironing machine GI-70-H so that you could make the double face lambskins perfect in quality with the wool well and fully ironed.
|参数名称Items||单 位Unit||数 值Parameter|
|驱动方式Driving method||电动、液压 Electric and Hydraulic|
|有效加工宽度Effective working width||毫 米mm||700|
|最大加热功率Max. heating power||千 瓦 kW||16.2|
|烫辊驱动功率Ironing cylinder driving power||千 瓦 kW||7.5|
|泵站功率Hydraulic power||千 瓦 kW||1.5|
|排风机功率Motor fan||千 瓦 kW||1.1|
|作业空间Working area||米 m||2.85×2.13×1.66|
|净 重Net weight||公 斤 kg||1290|
|毛 重 Gross weight||公 斤 kg||1698|
|装箱外形尺寸 Packing dimensions||米 m||1.90×1.90×1.68|
|体积 Volume||立方米 Cubic m||5|
|总 功 率Total power||千 瓦 kW||26.3|
